DECADE RESISTANCE BOXES

Mouseover on the image for a larger view.

Features
Independent Range selection
Direct read – out
Output on safety sockets
Moulded side covers with embossed handles
Membrane panel
Compact Design
Tolerance available up to 0.1%

Applications

Decade Resistance Boxes are used as a temporary resistive substitute for finding the optimum value of required resistance in laboratories for research & development.

Description

A wide range of resistance can be selected from a single row of switches, which allows direct read out from the position of control KNOBS. These resistance Boxes are designed to get resistance values by selecting any individual range between the decades ranges through the bottom mounted shrouded sockets. This reduce the residual resistance. Resistance boxes are available from 0.01Ω to 100MΩ with a general accuracy of 1% . high precision and high stability 2 watt non- inductive resistors are used.

Use of professional grade rotary switches of silver plated contacts with excellent dielectric material. The Resistors enclosed in metal cabinet or in an Aluminium extrusion body with handle embossed plastic side cover and multi color polycarbonate membrane panel to understand resistance color codes from the ranges easily by students.

Specially designed quality hardware components for easy user interface and highly professional and accurate testing and measuring instruments being used to calibrate these decade boxes.
